HUNTER TAPERED ISO A 1"-1.5" 4'X4' 1/8" SLOPE (38 PC/BD)

MacArthur #: 49A19HP101002

Manufacturer #: 317211HP

Manufacturer Product Family: Tapered Polyisocyanurate Insulation

Country of Origin: USA

U/M: Piece

Net weight: 4.46

Gross weight: 4.46

Insulation Thickness(in): 1"-1-1/2"

Pieces per carton: 38

Coverage Area Piece: 16

Coverage Area Unit: 608

Length (Ft): 4

Material: Polyiso

Series: TAPERED H-SHIELD

Width (Ft): 4

Hunter Tapered H-Shield is a sloped rigid roof insulation panel composed of a closed cell polyisocyanurate foam core manufactured on-line to a fiber reinforced facer on both sides. Tapered H-Shield is designed to promote positive drainage and prevent ponding water. This Panel comes in two grades of compressive strengths Grade 2 (20 psi) or Grade 3 (25 psi). Variety of slopes available including 1/8″, 1/4″ and 1/2″ per foot. See the Technical Data Sheet below for more information.

APPLICATIONS ƒ Approved for direct application to steel decks ƒ Approved under major roof coverings systems – BUR, Modified and Single-Ply ƒ Constructions requiring FM Class 1 and UL Class A ratings ƒ Single-Ply Roof Systems (Ballasted, Mechanically Attached, Fully Adhered) ƒ Modified Bitumen Systems ƒ Built-Up Roofing: Asphalt and Coal Tar ƒ To achieve optimal thermal performance, Hunter Panels recommends installation of a multi-layered system with staggered joints.
