ATCO DUCT FLEX SILVER INSUL R-6 POLY CORE 5" X 25'

MacArthur #: 30A0401035

Manufacturer #: 13602505

Our premium insulated duct has a double ply, metallized polyester vapor barrier with tri-directional reinforcements.

Manufacturer Product Family: UPC #036

U/M:  Piece

Net weight:  8.29

Gross weight:  8.29

Inside Diameter:  5

R-Value:  6

Length (Ft):  25

Weight Per Unit (LB):  8.29

ATCO #030, #036, and #031 are UL 181, Class 1 Air Ducts and are manufactured with a tri-directional fiberglass scrim reinforced, metallized polyester outer jacket. A double lamination of tough polyester which encapsulates a steel wire helix forms the air-tight inner core of the ATCO #030, #036, and #031. The double-layer core of each product is wrapped with a thick blanket of fiberglass insulation. The inner core of all three products is air tight and designed for low-to-medium operating pressures in HVAC systems. ATCO #036 and #031 have increased insulation for superior thermal performance.
